Faster Dashboards with Multi-Column Approximate Sorting
TL;DR: With any columnar data format, using advanced multi-column sorting when loading data can improve performance on a wide variety of selective read queries. Space filling curve encodings like Morton (Z-Order) and Hilbert approximately sort multiple columns together. Sorting by rounded timestamps adds additional benefits when filtering on recent data.
It is rare to have a dashboard with a single chart. It is even more rare to only query your data one way. It is rarer still to query your data with no filters at all!
When queries read a subset of the total rows, sorting data while loading provides significant benefits. Please have a look at the prior post in this series to understand how this approach works and for practical tips!
In order to see these benefits in a wider variety of real world cases, we have to get a bit more creative. These advanced techniques help when one of these situations occur:
- Queries filter on different columns
- Query patterns are not perfectly predictable
- Queries filter by time and at least one other column
In this post, we describe several advanced sorting strategies, compare them with some experiments (microbenchmarks), and then calculate a metric to measure their effectiveness.
The Strategy
Instead of sorting precisely by one or a small number of columns, we want to sort approximately by a larger number of columns.
That will allow queries with different WHERE
clauses to all benefit from DuckDB's min-max indexes (zone maps).
This post introduces two high-level approaches with several examples of each: sorting by space filling curves, and sorting by truncated timestamps.
Space Filling Curves
Both Morton and Hilbert are space filling curve algorithms that are designed to combine multiple columns into an order that preserves some approximate ordering for both columns. One application of space filling curves is in geospatial analytics and it is a helpful illustration.
If a dataset contained the latitude and longitude coordinates of every café on earth (one row per café), but we wanted to sort so that cafés that are physically close to one another are near each other in the list, we could use a space filling curve. Cafés that are somewhat close in both latitude and longitude will receive a similar Morton or Hilbert encoding value. This will allow us to quickly execute queries like “Find all cafés within this rectangular region on a map”. (A rectangular region like that is called a bounding box in geospatial-land!) The GIF at the top of this post shows various levels of granularity of a Hilbert encoding – imagine if the x axis were longitude and the y axis were latitude. The "zig-zag" line of the Hilbert algorithm is the list of cafés, sorted approximately.
Both Morton and Hilbert operate on integers or floats, but this post outlines a way to use them to sort VARCHAR
columns as well.
A SQL macro is used to convert the first few characters of a VARCHAR
column into an integer as a pre-processing step.
Truncated Timestamps
More recent data tends to be more useful data, so frequently queries filter on a time column. However, often queries filter on time and on other columns as well.
Don't just sort on the timestamp column!
You will miss out on performance benefits.
This is because timestamps tend to be so granular, that in practical terms the data is only sorted by timestamp.
How many rows of your data were inserted at exactly 2025-01-01 01:02:03.456789
?
Probably just one!
To sort on multiple columns as well as a time column, first sort by a truncated timestamp (truncated to the start of the day, week, year, etc.) and then on the other columns.
The “On-Time Flights” Dataset
Ever wondered how likely you will be delayed when you are getting ready to fly? If you are traveling in the US, you can use a government dataset to see how on-time each route is! You can get more details on the dataset at its official site, but I grabbed a Parquet version of the data from Kaggle. It includes almost 5 years of data on US flights. Combined, the Parquet files are about 1.1 GB. This is fairly small when accessed locally but can be more of a challenge over a slow remote connection. In the rest of the post, we'll run different benchmarks to demonstrate how pruning can help reducing the amount of network traffic required to answer certain queries.
Our first experiment is a hypothetical use case to serve a dashboard where people can explore a single origin
, a single dest
(destination), or an origin
–dest
pair.
The origin
and dest
columns are three-letter airport codes (like LAX
or JFK
).
We assume once you have picked one of those filters, you want all the rows that match and a few arbitrary columns.
Our second experiment will add in a time component where our hypothetical users could additionally filter to the latest 1, 13, or 52 weeks of data in the dataset.
Experimental Design
We will show a few approaches to sort data approximately to speed up retrieval.
The control groups are:
random
: Sort by a hash – the worst case scenario!origin
: Single-column sort onorigin
origin-dest
: Sort onorigin
, then ondestination
Our alternative sorting approaches are:
zipped_varchar
: Sort by one letter at a time, alternating betweenorigin
anddestination
. – For example, anorigin
ofABC
and adestination
ofXYZ
would becomeAXBYCZ
, which would then be sorted.morton
: Convertorigin
anddestination
into integers, then order by Morton encoding (Z-order)hilbert
: Convertorigin
anddestination
into integers, then order by Hilbert encoding
The
zipped_varchar
algorithm is implemented using a SQL macro so no extensions are needed. It also handles arbitrary length strings.
The Morton and Hilbert encoding functions come from the
lindel
DuckDB community extension, contributed by Rusty Conover. Thank you to Rusty and the folks who have built thelindel
Rust crate upon which the DuckDB extension is based! Thespatial
extension also contains anST_Hilbert
function that works similarly. Thanks to Max Gabrielsson and the GDAL community!
These plots display query runtime when pulling from a DuckDB file hosted on S3. These same techniques can also be successfully applied to the DuckLake integrated data lake and catalog format! DuckLake is the modern evolution of the cloud data lakehouse – take a minute to check out the launch post if you haven't yet! DuckLake has an additional concept of a partition, which enables entire files to be skipped. To take full advantage of DuckLake, first partition your data (by time or otherwise) and then apply the techniques in this post when loading your data.
All experiments were run on an M1 MacBook Pro with DuckDB v1.2.2. The tests were conducted with the DuckDB Python client with results returned as Apache Arrow tables. In between each query, the DuckDB connection is closed and recreated (this time is not measured as a part of the results). This is to better simulate a single user's experience accessing the dashboard in our hypothetical use case.
Expand to see the basic sorting queries
For reproducibility, here are the very standard queries used to initially load the data from Parquet, sort randomly, sort by origin
, and sort by origin
and then destination
.
The parquet files were downloaded from Kaggle.
CREATE TABLE IF NOT EXISTS flights AS
FROM './Combined_Flights*.parquet';
-- The hash function is used instead of random
-- for consistency across re-runs
CREATE TABLE IF NOT EXISTS flights_random AS
FROM flights
ORDER BY hash(rowid + 42);
CREATE TABLE IF NOT EXISTS flights_origin AS
FROM flights
ORDER BY origin;
CREATE TABLE IF NOT EXISTS flights_origin_dest AS
FROM flights
ORDER BY origin, dest;
Expand to see the Zipped VARCHAR
sorting queries
As an example of an approach that does not require an extension, this SQL macro roughly approximates a space filling curve approach, but using alphanumeric characters instead of integers. The outcome is a dataset that is somewhat sorted by one column and somewhat sorted by another.
CREATE OR REPLACE FUNCTION main.zip_varchar(i, j, num_chars := 6) AS (
-- By default using 6 characters from each string so that
-- if data is ASCII, we can fit it all in 12 bytes so that it is stored inline
-- rather than requiring a pointer
[
list_value(z[1], z[2])
FOR z
IN list_zip(
substr(i, 1, num_chars).rpad(num_chars, ' ').string_split(''),
substr(j, 1, num_chars).rpad(num_chars, ' ').string_split('')
)
].flatten().array_to_string('')
);
CREATE TABLE IF NOT EXISTS flights_zipped_varchar AS
FROM flights
ORDER BY
main.zip_varchar(origin, dest, num_chars := 3);
Here is an example of the output that the zip_varchar
function produces:
SELECT
'ABC' AS origin,
'XYZ' AS dest,
main.zip_varchar(origin, dest, num_chars := 3) AS zipped_varchar;
origin | dest | zipped_varchar |
---|---|---|
ABC | XYZ | AXBYCZ |
Expand to see the Morton and Hilbert sorting queries
The goal of a space filling curve is to map multiple dimensions (in our case, two: origin
and destination
) down to a single dimension, but to preserve the higher dimension locality between data points.
Morton and Hilbert encodings are designed to accept integers or floating point numbers.
However, in our examples, we want to apply these techniques to VARCHAR
columns.
Strings actually encode a substantial amount of data per length of the string. This is because numbers can only have 10 values per digit (in our base 10 numbering system), but a string can have many more (all lowercase letters, capital letters, or symbols). As a result, we are not able to encode very long strings into integers – only the first few characters. This will still work for our approximate sorting use case!
This SQL function can convert a VARCHAR
containing ASCII characters (up to 8 characters in length) into a UBIGINT
.
It splits the VARCHAR
up into individual characters, calculates the ASCII number for that character, converts that to bits, concatenates the bits together, then converts to a UBIGINT
.
CREATE OR REPLACE FUNCTION main.varchar_to_ubigint(i, num_chars := 8) AS (
-- The maximum number of characters that will fit in a UBIGINT is 8
-- and a UBIGINT is the largest type that the lindel community extension accepts for Hilbert or Morton encoding
list_reduce(
[
ascii(my_letter)::UTINYINT::BIT::VARCHAR
FOR my_letter
IN (i[:num_chars]).rpad(num_chars, ' ').string_split('')
],
(x, y) -> x || y
)::BIT::UBIGINT
);
The morton_encode
and hilbert_encode
functions from the lindel
community extension can then be used within the ORDER BY
clause to sort by the Morton or Hilbert encoding.
INSTALL lindel FROM community;
LOAD lindel;
CREATE TABLE IF NOT EXISTS flights_morton AS
FROM flights
ORDER BY
morton_encode([
varchar_to_ubigint(origin, num_chars := 3),
varchar_to_ubigint(dest, num_chars := 3)
]::UBIGINT[2]);
CREATE TABLE IF NOT EXISTS flights_hilbert AS
FROM flights
ORDER BY
hilbert_encode([
varchar_to_ubigint(origin, num_chars := 3),
varchar_to_ubigint(dest, num_chars := 3)
]::UBIGINT[2]);
Alternatively, the spatial
extension can be used to execute a Hilbert encoding.
It requires a bounding box to be supplied, as this helps determine the granularity of the encoding for geospatial use cases.
It performed similarly to the Hilbert approach included in the experimental results.
SET VARIABLE bounding_box = (
WITH flights_converted_to_ubigint AS (
FROM flights
SELECT
*,
varchar_to_ubigint(origin, num_chars := 3) AS origin_ubigint,
varchar_to_ubigint(dest, num_chars := 3) AS dest_ubigint
)
FROM flights_converted_to_ubigint
SELECT {
min_x: min(origin_ubigint),
min_y: min(dest_ubigint),
max_x: max(origin_ubigint),
max_y: max(dest_ubigint)
}::BOX_2D
);
CREATE OR REPLACE TABLE flights_hilbert_spatial AS
FROM flights
ORDER BY
ST_Hilbert(
varchar_to_ubigint(origin, num_chars := 3),
varchar_to_ubigint(dest, num_chars := 3),
getvariable('bounding_box')
);
Expand to see the selective read queries used to measure performance
In summary, this microbenchmark tests:
- Querying tables sorted by the 6 different approaches (3 control and 3 advanced)
- Filtering using three query patterns: filters on
origin
,destination
, andorigin
/destination
- Filtering with 4 different
origin
/dest
pairs:- SFO – LAX
- LAX – SFO
- ORD – LGA
- LGA – ORD
Each of these 72 unique queries are repeated 3 times for a total of 216 queries. All are included in the resulting plots.
FROM sorted_table
SELECT flightdate, airline, origin, dest, deptime, arrtime
WHERE origin = origin;
FROM sorted_table
SELECT flightdate, airline, origin, dest, deptime, arrtime
WHERE dest = dest;
FROM sorted_table
SELECT flightdate, airline, origin, dest, deptime, arrtime
WHERE origin = origin AND dest = dest;
Experimental Results
We can see that when filtering by origin
, the origin
single column sort is a full order of magnitude faster than randomly distributed data, requiring only 1.6 seconds instead of 16.
Our advanced techniques are nearly as fast as the dedicated sort on origin
.
However, if you look at the plot by destination
, we see the value of the more balanced techniques.
The origin_dest
approach of just appending destination
to the list of sorted columns misses out on much of the benefits.
When querying for a specific origin
and destination
pair, all approaches are significantly faster than random.
However, zooming in on the non-random techniques, the more advanced sorting approaches are as fast or slightly faster than sorting by origin
or by origin
and then destination
.
Performance is also faster than the other experiments, as less data needs to be read (since the filter is more selective).
The Hilbert encoding method provides the most consistent performance across the three query patterns. It would be the best choice to support all 3 workloads.
Approximate Time Sorting
Sorting by an “approximate time” involves truncating the time to the nearest value of a certain time granularity.
In this experiment, we load the data with 3 different sorting approaches.
We first sort on a truncation of the flightdate
column, truncated to either day, month, or year.
We then use our most effective multi-column approach and sort by the Hilbert encoding of origin
and dest
next.
When measuring performance, we test each of the query patterns tested previously (filters on origin
, destination
, and origin
/ destination
), but additionally filter on three different time ranges: the latest 1 week, 13 weeks, and 52 weeks.
Expand to see the approximate time sorting queries
CREATE TABLE IF NOT EXISTS flights_hilbert_day AS
FROM flights
ORDER BY
date_trunc('day', flightdate),
hilbert_encode([
varchar_to_ubigint(origin, num_chars := 3),
varchar_to_ubigint(dest, num_chars := 3)
]::UBIGINT[2]);
CREATE TABLE IF NOT EXISTS flights_hilbert_month AS
FROM flights
ORDER BY
date_trunc('month', flightdate),
hilbert_encode([
varchar_to_ubigint(origin, num_chars := 3),
varchar_to_ubigint(dest, num_chars := 3)
]::UBIGINT[2]);
CREATE TABLE IF NOT EXISTS flights_hilbert_year AS
FROM flights
ORDER BY
date_trunc('year', flightdate),
hilbert_encode([
varchar_to_ubigint(origin, num_chars := 3),
varchar_to_ubigint(dest, num_chars := 3)
]::UBIGINT[2]);
Expand to see the selective read queries used to measure performance
In summary, this microbenchmark tests:
- Querying tables sorted with
flightdate
truncated to three levels of granularity: day, month, and year, then by Hilbert encoding. - Filtering on three time ranges: the latest 1 week, 13 weeks, and 52 weeks
- Filtering on
origin
,destination
, andorigin
/destination
- Filtering with 4 different
origin
/dest
pairs:- SFO – LAX
- LAX – SFO
- ORD – LGA
- LGA – ORD
Each of these 108 unique queries are repeated 3 times for a total of 324 queries.
FROM sorted_table
SELECT flightdate, airline, origin, dest, deptime, arrtime
WHERE
origin = origin
AND flightdate >= ('2022-07-31'::TIMESTAMP – INTERVAL time_range WEEKS);
FROM sorted_table
SELECT flightdate, airline, origin, dest, deptime, arrtime
WHERE
dest = dest
AND flightdate >= ('2022-07-31'::TIMESTAMP – INTERVAL time_range WEEKS);
FROM sorted_table
SELECT flightdate, airline, origin, dest, deptime, arrtime
WHERE
origin = origin
AND dest = dest
AND flightdate >= ('2022-07-31'::TIMESTAMP – INTERVAL time_range WEEKS);
When querying a week of data for a specific origin
, sorting at the daily level performs the best.
However, sorting by a more approximate time (month or year) performs better when analyzing the latest 13 or 52 weeks of data.
This is because the more approximate time buckets allow the Hilbert encoding to separate origin
s into different row groups more effectively.
Querying by time and destination follows a very similar pattern, with the ideal sort order being highly dependent on how far back in time is analyzed.
Filtering by origin
and destination
shows a very different outcome, with a yearly granularity being superior across the board!
This is because the origin
and destination
filters are much more effective at skipping row groups when the timestamp ordering is very approximate.
As a result, the best compromise across those three workloads is likely to be the very approximate yearly granularity. See! Don't just sort by timestamp!
Table Creation Time
The upfront investment required to see these benefits is the time required to sort the data when inserting. Typically this is still a good trade off – data inserts tend to happen in the background, but nobody wants to be staring at dashboard loading spinners!
Creating a DuckDB table from Parquet files without sorting took slightly over 21 seconds. Each other approach copied from the unsorted DuckDB table and created a new table. The various methods of sorting required similar amounts of time (between 48 and 61 seconds), so we are free to choose the one with the most effective results without considering relative insert performance. However, it is worth noting that overall insert performance slows down by nearly 3× with any sorting.
Table name | Creation time (s) |
---|---|
from_parquet |
21.4 |
random |
60.2 |
origin |
51.9 |
origin_dest |
48.7 |
zipped_varchar |
58.2 |
morton |
54.6 |
hilbert |
58.5 |
hilbert_day |
58.7 |
hilbert_month |
53.8 |
hilbert_year |
60.2 |
Measuring Sortedness
The most effective way to choose a sort order is to simulate your production workload, like in the experiments above. However, this is not always feasible or easy to do. Instead, we can measure how well sorted the dataset is on the columns of interest. The metric we will use is “Number of Row Groups per Value”. The way to interpret this is that for selective queries to work effectively, each value being filtered on should only be present in a small number of row groups. Smaller is better! However, there are likely diminishing returns when this metric is below the number of threads DuckDB is using.
Other database systems measure a similar metric called "Clustering Depth".
What can be interpreted from this graph?
The random ordering spreads nearly every value across 100 or more row groups (the visualization is truncated at 100 row groups for readability).
This highlights how a random ordering will be very slow for selective queries!
Sorting by origin
greatly reduces the number of row groups that each origin
is spread across, but destination
s are still spread widely.
Sorting by origin
and destination
retains the tight distribution of origin
s and slightly improves the metric for destination
s.
The three advanced approaches (zipped_varchar
, morton
, and hilbert
) are more balanced, with both origin
s and destination
s only occuring in a moderate number of row groups.
While they score worse in the origin
metric than when sorting directly by origin
, most origin
s are spread across fewer row groups than a modern laptop processor's core count, so high performance is retained.
The Hilbert encoding is the most balanced, so by this metric it would be declared the victor as well!
To calculate this metric, we define several SQL macros using dynamic SQL and the query
table function.
Expand to see the macros for calculating “Number of Row Groups per Value”
-- These are helper functions for writing dynamic SQL
-- sq = single quotes
-- dq = double quotes
-- nq = no quotes
CREATE OR REPLACE FUNCTION sq(my_varchar) AS (
'''' || replace(my_varchar,'''', '''''') || ''''
);
CREATE OR REPLACE FUNCTION dq(my_varchar) AS (
'"' || replace(my_varchar,'"', '""') || '"'
);
CREATE OR REPLACE FUNCTION nq(my_varchar) AS (
replace(my_varchar, ';', 'No semicolons are permitted here')
);
CREATE OR REPLACE FUNCTION dq_list(my_list) AS (
list_transform(my_list, (i) -> dq(i))
);
CREATE OR REPLACE FUNCTION nq_list(my_list) AS (
list_transform(my_list, (i) -> nq(i))
);
CREATE OR REPLACE FUNCTION dq_concat(my_list, separator) AS (
list_reduce(dq_list(my_list), (x, y) -> x || separator || y)
);
CREATE OR REPLACE FUNCTION nq_concat(my_list, separator) AS (
list_reduce(nq_list(my_list), (x, y) -> x || separator || y)
);
-- This function produces the "Number of row groups per Value" boxplot
CREATE OR REPLACE FUNCTION rowgroup_counts(table_name, column_list) AS TABLE (
FROM query('
WITH by_rowgroup_id AS (
FROM ' || dq(table_name) || '
SELECT
ceiling((count(*) OVER ()) / 122_880) AS total_row_groups,
floor(rowid / 122_880) AS rowgroup_id,
' || dq_concat(column_list, ',') || '
), rowgroup_id_counts AS (
FROM by_rowgroup_id
SELECT
case ' ||
nq_concat(list_transform(column_list, (i) -> ' when grouping(' || dq(i) || ') = 0 then alias(' || dq(i) || ') '),' ')
|| ' end AS column_name,
coalesce(*columns(* exclude (rowgroup_id, total_row_groups))) AS column_value,
first(total_row_groups) AS total_row_groups,
count(distinct rowgroup_id) AS rowgroup_id_count
GROUP BY
GROUPING SETS ( ' || nq_concat(list_transform(dq_list(column_list), (j) -> '(' || j || ')'), ', ') ||' )
)
FROM rowgroup_id_counts
SELECT
' || sq(table_name) || ' AS table_name,
*
ORDER BY
column_name
')
);
-- This is an optional function that can summarize the data
-- as an alternative to boxplot charts
CREATE OR REPLACE FUNCTION summarize_rowgroup_counts(table_name, column_list) AS TABLE (
FROM rowgroup_counts(table_name, column_list)
SELECT
table_name,
column_name,
total_row_groups,
min(rowgroup_id_count) AS min_cluster_depth,
avg(rowgroup_id_count) AS avg_cluster_depth,
max(rowgroup_id_count) AS max_cluster_depth,
map([0.1, 0.25, 0.5, 0.75, 0.9], quantile_cont(rowgroup_id_count, [0.1, 0.25, 0.5, 0.75, 0.9]))::JSON AS quantiles,
histogram(rowgroup_id_count, [1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 32, 64, 128, 256])::JSON AS histograms,
GROUP BY ALL
ORDER BY ALL
);
We can then call the rowgroup_counts
function on any table and any columns!
FROM rowgroup_counts('flights_hilbert', ['origin', 'dest']);
table_name | column_name | column_value | total_row_groups | rowgroup_id_count |
---|---|---|---|---|
flights_hilbert | dest | PSG | 238 | 2 |
flights_hilbert | dest | ESC | 238 | 2 |
flights_hilbert | origin | YUM | 238 | 2 |
… | … | … | … | … |
The rowgroup_id_count
column is a measurement of how many distinct row groups that a specific column value is present in, so it is an indicator of how much work DuckDB would need to do to pull all data associated with that value.
This calculation uses the pseudo-column
rowid
, and it requires data to have been inserted in a single batch to be perfectly accurate. It is only an approximate metric when data is inserted in batches.
Conclusion
When storing data in a columnar file format like a DuckDB database or a Parquet file, approximately sorting by multiple columns can lead to fast read queries across a variety of query patterns. Sorting using the Hilbert encoding provided high performance across multiple workloads, and sorting by year and then by Hilbert performed well when also filtering by time.
Thanks to the "Number of Row Groups per Value" calculation, we can measure the sortedness of any table by any column, and it was predictive of the experimental performance we observed. This way we can experiment with different sorting approaches and quickly forecast their effectiveness, without having to benchmark read workloads each time.
Using these approaches can greatly speed up dashboard interactivity when users are unpredictable (which we always are!). They can also be used in combination with the the additional techniques outlined in the prior post for further benefits. Data is always different, so we get to be creative!
Happy analyzing, folks!
